Product Details

Product Description

WORKMASTER compacts feature the same rugged buckle-up driveline design found on New Holland Ag tractors so you know they are built to last. They use powerful, yet fuel efficient, 3 cylinder diesel engines to help you tackle your toughest tasks.

Whether you maintain a food plot on the nights and weekends, tend to a small herd of livestock, or work in professional landscaping, you owe it to yourself to explore New Holland’s family of WORKMASTER compact tractors. Known for delivering outstanding value for their performance, these reliable, powerful, and easy-to-operate tractors will help you tackle your to-do list while being easy on your wallet.

Dimensions

Dimensions/Weight
	25HP	35HP	45HP
Wheelbase in. (mm)	65.9 (1674)	67.5 (1715)	67.5 (1715)
Length in. (mm)	117.2 (2976)	121 (3074)	121 (3074)
Width in. (mm)	63.7 (1618)	66.5 (1689)	66.5 (1689)
Height (top of ROPS or Cab) in. (mm)	88.2 (2241)	87.7 (2227)	87.7 (2227)
Weight lb. (kg)	2469 (1120)	3067 (1391)	3067 (1391)

Specifications

Engine
	25HP	35HP	45HP
Emissions Level	T4B Final	T4B Final	T4B Final
Gross horsepower hp (kW)	24.7 (18.2)	35 (26.1)	40 (29.2)
Rated speed rpm	2500	2600	2600
No. of cylinders	3	3	3
Aspiration	Natural	Turbo	Turbo
Displacement cu.in. (L)	80.4 (1.3)	114.7 (1.9)	114.7 (1.9)
Alternator amps	50	70	70
Fuel Tank gal. (L)	7.4 (28)	7.4 (28)	7.4 (28)

PTO
	25HP	35HP	45HP
PTO horsepower hp (kW)	19.0 (14.1) Gear 17.0 (12.7) HST	29.7 (22.1) Gear / 28.0 (20.9) HST	34.0 (25.4) Gear / 32.0 (23.9) HST
PTO speed rpm	540	540	540
PTO type	Independent Electro-Hydraulic Engagement	Independent Electro-Hydraulic Engagement	Independent Electro-Hydraulic Engagement

Transmission
	25HP	35HP	45HP
Type/Control – Choice 1	12×12 Gear	12×12 Gear	12×12 Gear
Type/Control – Choice 2	3 Range Hydrostatic/Dual Pedal	3-Range Hydrostatic / Dual Pedal	3-Range Hydrostatic / Dual Pedal
Cruise control	Standard HST	Standard HST	Standard HST
Maximum forward speed mph (kph)	13.8 (22.2) Gear 15.3 (24.7) HST	14.2 (22.9) Gear / 14.8 (23.9) HST	14.2 (22.9) Gear / 14.8 (23.9) HST

Hydraulics & 3-Point
	25HP	35HP	45HP
Implement hydraulic gpm (Lpm)	7.9 (30)	8.2 (31)	8.2 (31)
Steering hydraulic gpm (Lpm)	4.6 (17.5) Gear 4.6 (17.5) HST	4.2 (15.9) Gear / 5.3 (19.9) HST	4.2 (15.9) Gear / 5.3 (19.9) HST
Total flow gpm (Lpm)	12.5 (47.5) Gear 12.5 (47.5) HST	12.4 (46.8) Gear / 13.5 (50.8) HST	12.4 (46.8) Gear / 13.5 (50.8) HST
Remote Valves	1 or 2 Opt.	1 or 2 Opt.	1 or 2 Opt.
3-point hitch	Telescopic Stabilizer /Fixed Link Ends	Telescopic Stabilizer / Fixed Link Ends	Telescopic Stabilizer / Fixed Link Ends
3PT lift capacity @ ball ends lb. (kg)	1808 (820)	1808 (820)	1808 (820)
3PT lift capacity @ 24 in. (610 mm) behind ball ends lb. (kg)	1433 (650)	1433 (650)	1433 (650)

Photo Gallery

VIDEO

KEY FEATURES

RUGGED DESIGN, FUEL-EFFICIENT POWER WORKMASTER compacts feature the same rugged buckle-up driveline design found on New Holland ag tractors so you know they are built to last. They use powerful, yet fuel efficient, 3 cylinder diesel engines to help you tackle your toughest tasks.
BOOMER GUARD 6 You’ll have peace of mind knowing that New Holland’s Boomer Guard 6 limited warranty includes 2 years of bumper-to-bumper coverage, plus an extra 4 years of powertrain protection.
EASY ON AND OFF Roomy, no-clutter operating platform gives you an open path to the seat.
VERSATILE TRANSMISSION With its well placed, clearly marked and color coded controls you’ll be operating a WORKMASTER™ compact tractor like a pro in no time.
